New SiC MOSFET for EV drive trains reduces range anxiety

0
Silicon carbide (SiC) power products provider Wolfspeed, has introduced a 900V, 10m ohm (Ω) metal–oxide–semiconductor field-effect transistor (MOSFET) for the reduction of EV drive-train inverter losses.
New SiC MOSFET for EV drive trains reduces range anxiety

The new MOSFET is rated for 196 A of continuous drain current at a case temperature of 25°C, enabling the reduction of EV drive-train inverter losses by 78 percent based on EPA combined city/highway mileage standards. This efficiency improvement offers designers new options in terms of range, battery usage and vehicle design.

Recently Wolfspeed supplied Ford Motor Company – in a collaboration with the US Department of Energy (DoE) – with a full-SiC, 400A power module designed around the 900V, 10mΩ chip.  The module, designed and produced by Wolfspeed, contains four MOSFETs connected in parallel to achieved a remarkable 2.5mΩ Rds(on). Wolfspeed engineers have since demonstrated the capability to use these chps to create an 800A, 1.25mΩ module.

“With the commercial release of the 900V 10mΩ device, electric vehicles can now reap the benefits of SiC in all aspects of their power conversion” said John Palmour, CTO of Wolfspeed. “With the continued expansion of our Gen3 MOSFET portfolio in new package options, our devices can now support significant efficiency improvements in onboard chargers, offboard chargers, and now EV drive trains.”

Commercially qualified and rated for a maximum operating temperature of 175˚C, Wolfspeed’s new chip offers high-reliability in harsh environments, like those found in vehicle drive-trains.

The new 900V, 10mΩ MOSFET is currently available in bare die. Wolfspeed expects to release the associated discrete device in a 4L-TO247 package (C3M0010090K) in the coming weeks. This package has a Kelvin-source connection that allows engineers to create designs that maximize the benefits of SiC’s superior speed and efficiency.

Image: Vauxhall Ampera
