The project known as Retrofit Plus, has been carried out by alongside Birmingham City University, to see how changes made to houses could cut heating energy bills and lift low-income households out of fuel poverty.
Two semi-detached houses in the Shard End area of Birmingham were handed over to the project by Birmingham City Council last year. Residents were able to continue living in the properties while the changes were carried out. The process saw a range of energy efficient measures introduced including fitting the houses with Beattie Passive’s TCosy Deep Retrofit system. TCosy wraps entire buildings with a new insulated layer by installing a timber frame structure completely around the homes and injecting insulation material into the walls and roof cavity. This creates a continuous insulated layer around the building, eliminating heat loss and making the buildings draught free – forming a process which can be ‘retrofitted’ to refurbish existing homes.
As part of the retrofit solution, new triple glazed windows and doors as well as a mechanical ventilation and heat recovery system were installed. The whole system was built to low-energy Passivhaus standards, offering advanced energy and comfort levels. The houses have also been fitted with high-tech sensors and controls which automatically regulate the houses’ temperatures as well as learning and reacting to residents’ patterns of use.
Since work began in September the results have shown an 80 per cent reduction in the use of energy and residents have reported major improvements. It is hoped the scheme could increase the value of housing stock for councils and regenerate areas of deprivation by also fitting homes with high quality new facades.
“This project took our TCosy innovation forward to an offsite manufactured panel” said Ron Beattie of Beattie Passive. “This has greatly increased the speed of works and with further innovations we expect to see the process become quicker and more affordable. We have received many positive comments from the tenants of our retrofitted properties who are already enjoying a warmer, healthier Passivhaus living environment as well as reduced energy bills.”
Professor Lubo Jankovic, Head of the Zero Carbon Lab at Birmingham City University’s School of Architecture and Design, added that retrofit has been shown to reduce heating energy consumption and carbon emissions by 80 per cent, saving money for residents and providing a process suitable for a UK-wide scaling-up. The project also shows that there is a behaviour change with occupants with increased internal temperatures and fewer warm clothes needed in winter. This approach improves health and wellbeing of occupants and positively changes their lives.
Birmingham City University provided simulation design analysis of the houses, tracked their carbon outputs and InteSys Ltd developed a predictive control system which learns physical characteristics of the building and delivers the right amount of heat at the right time. Thermal imaging and 3D laser scanning formed a part of detailed pre-retrofit survey that enabled the creation of design simulation models to help plan the best way to achieve a zero-carbon rating and monitor the changes in energy consumption. The houses have now formally been handed back to Birmingham City Council but their energy use will continue to be monitored until later this summer.
