NREL research indicates potential significant thermoelectric performance

Research conducted by the US National Renewable Energy Laboratory (NREL) has found that adding thin films to fabrics can power portable electronics sensors.
NREL research indicates potential significant thermoelectric performance

Scientists at the US Department of Energy’s National Renewable Energy Laboratory (NREL) have reported significant advances in the thermoelectric performance of organic semiconductors based on carbon nanotube thin films that could be integrated into fabrics to convert waste heat into electricity or serve as a small power source.

The research demonstrates significant potential for semiconducting single-walled carbon nanotubes (SWCNTs) as the primary material for efficient thermoelectric generators, rather than being used as a component in a “composite” thermoelectric material containing, for example, carbon nanotubes and a polymer. The discovery is outlined in the new Energy & Environmental Science paper, Large n- and p-type thermoelectric power factors from doped semiconducting single-walled carbon nanotube thin films.

“There are some inherent advantages to doing things this way” said Jeffrey Blackburn, a senior scientist in NREL’s Chemical and Materials Science and Technology centre and co-lead author of the paper with Andrew Ferguson. These advantages include the promise of solution-processed semiconductors that are lightweight and flexible and inexpensive to manufacture. Blackburn worked on the project with a number of other NREL researchers - Bradley MacLeod, Rachelle Ihly, Zbyslaw Owczarczyk, and Katherine Hurst. The scientists also teamed up with collaborators from the University of Denver and partners at International Thermodyne, Inc., based in Charlotte, North Carolina.

Ferguson, also a senior scientist in the Chemical and Materials Science and Technology centre, added that the introduction of SWCNT into fabrics could serve an important function for “wearable” personal electronics. By capturing body heat and converting it into electricity, the semiconductor could power portable electronics or sensors embedded in clothing.

Blackburn and Ferguson published two papers last year on SWCNTs, and the new research builds on their earlier work. The first paper, in Nature Energy, showed the potential that SWCNTs have for thermoelectric applications, but the films prepared in this study retained a large amount of insulating polymer. The second paper, in ACS Energy Letters, demonstrated that removing this “sorting” polymer from an exemplary SWNCT thin film improved thermoelectric properties.

The newest paper revealed that removing polymers from all SWCNT starting materials served to boost the thermoelectric performance and lead to improvements in how charge carriers move through the semiconductor. The paper also demonstrated that the same SWCNT thin film achieved identical performance when doped with either positive or negative charge carriers. These two types of material - called the p-type and the n-type legs, respectively - are needed to generate sufficient power in a thermoelectric device. Semiconducting polymers, another heavily studied organic thermoelectric material, typically produce n-type materials that perform much worse than their p-type counterparts. The fact that SWCNT thin films can make p-type and n-type legs out of the same material with identical performance means that the electrical current in each leg is inherently balanced, which should simplify the fabrication of a device. The highest performing materials had performance metrics that exceed current state-of-the-art solution-processed semiconducting polymer organic thermoelectrics materials.

“We could actually fabricate the device from a single material” Ferguson said. “In traditional thermoelectric materials you have to take one piece that’s p-type and one piece that’s n-type and then assemble those into a device.”

The research was funded by a cooperative research and development agreement (CRADA) with partner International Thermodyne. The fundamental research in SWCNT separation and optical/electrical characterisation is supported by the US Department of Energy’s Office of Science.

NREL is the US Department of Energy's primary national laboratory for renewable energy and energy efficiency research and development, operated for the Energy Department by The Alliance for Sustainable Energy, LLC.

Image: NREL scientists Andrew Ferguson, left, and Jeffrey Blackburn stand in front of a screen displaying single-walled carbon nanotubes. (Photo by Dennis Schroeder/NREL)
