Drive System Design’s expanded test facilities help accelerate commercial EV development

Electrified powertrain engineering consultancy, Drive System Design (DSD) has expanded its test facilities, adding two further test cells for high-performance hybrid axles and e-machines.
Drive System Design’s expanded test facilities help accelerate commercial EV development
DSD's expanded test facilities. Courtesy of Drive System Design (DSD)

The company’s recent expansion of its test facilities reflects a growing demand for outsourced test capacity suitable for electrified CV powertrains. The first of the new facilities can deliver input torque up to 2,500Nm and power up to 525kW, with 350kW and 1,100V of battery emulation; the second accommodates e-machines up to 350kW. The new cells complement existing DSD facilities, which include a 450kW highly transient ETPS machine (Engine Torque Pulse Simulator) for hybridised powertrains and three battery emulators.

“As global pressure grows to reduce transport’s contribution to climate change, commercial vehicle manufacturers are turning to electrification in the same way as passenger car manufacturers” said David Kelly, Director, Drive System Design. “This has resulted in a significant increase in worldwide demand, not only for design and development work but also for outsourced validation testing. These additional facilities have extended our ability to provide this for a wide range of hybrid and electric powertrains, and have been configured with sufficient torque capacity to accommodate most commercial vehicles below class 8. The duty cycles appropriate for electrified CV powertrains are very different to those for passenger cars, so we are providing engineering support to customers moving into this sector for the first time. On the other hand, even customers with long experience in CVs are being surprised by the speed with which the market is changing and are struggling to accommodate the upsurge in test requirements using solely in-house facilities.”

DSD’s testing activities extend beyond routine durability and design validation to encompass many specialised areas, such as transmission control system and shift comfort development. For some clients in the CV sector, electric propulsion requires new skills beyond their established expertise, where DSD’s input is proving invaluable. Even for those more experienced in electric propulsion, the sheer volume of testing required to bring new electrified powertrains to market is causing bottlenecks in capacity that can only be resolved through outsourcing to trusted partners.

DSD is continually developing its automation capabilities within the new facility to help speed up testing. This has been particularly effective in the case of hot and cold environment testing, which is proving to be one of the great challenges in electrified systems. According to Kelly, tests that previously took six weeks to complete can be finished in half that time with suitably configured automatic control.

Alongside physical testing, DSD is also at the forefront of powertrain and driveline simulation. The growing diversity of propulsion systems and the increasing complexity of their control mean traditional validation techniques are often too slow, too inefficient and too expensive to meet new vehicle program targets, if used in isolation.

For additional information:

Drive System Design (DSD)
